| CPU | AM4 Socket: Supports AMD 3rd Gen Ryzen/ 2nd Gen Ryzen/ 1st Gen Ryzen/ 2nd Gen Ryzen with Radeon Vega Graphics/ 1st Gen Ryzen with Radeon Vega Graphics/ Athlon with Radeonˆž Vega Graphics Processors |
| Chipset | AMD B450 |
| Memory | 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory |
| Dual channel memory architecture | |
| Support for DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/2933/2667/2400/2133 MHz memory modules | |
| Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | |
| Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
| Support for Extreme Memory Profile (XMP) memory modules | |
| Onboard Graphics | |
| Integrated Graphics Processor: | 1. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz |
| * The DVI-D port does not support D-Sub connection by adapter. | |
| 2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz(Note) | |
| * Support for HDMI 2.0 version and HDCP 2.2.(Note) | |
| Maximum shared memory of 16 GB | |
| Audio | RealtekÆALC887 codec |
| High Definition Audio | |
| 2/4/5.1/7.1-channel | |
| * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. | |
| Support for S/PDIF Out | |
| LAN | RealtekÆGbE LAN chip (10/100/1000 Mbit) |
| Expansion Slots | |
| 1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note) | |
| * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. | |
| (The PCIEX16 slot conforms to PCI Express 3.0 standard.) | |
| 1 x PCI Express x16 slot, running at x4 (PCIEX4) | |
| 1. 1 x PCI Express x1 slot | |
| (The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.) | |
| (Note) Actual support may vary by CPU. | |
| Multi-Graphics Technology | |
| Support for AMD Quad-GPU CrossFireô and 2-Way AMD CrossFireô technologies | |
| Storage Interface | |
| 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2* SSD support) | |
| * Actual support may vary by CPU. | |
| * Supports only M.2 SATA SSDs when using an AMD Athlonô-series/ 7th Gen. A-series or Athlonô X4 APU. | |
| 4 x SATA 6Gb/s connectors | |
| Support for RAID 0, RAID 1, and RAID 10 | |
| Chipset: | 1. 2 x USB 3.1 Gen 1 ports available through the internal USB header |
| 2. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) | |
| CPU: | 1. 4 x USB 3.1 Gen 1 ports on the back panel |
| Internal I/O Connectors | |
| 1 x 24-pin ATX main power connector | |
| 1 x 8-pin ATX 12V power connector | |
| 1 x CPU fan header | |
| 1 x system fan header | |
| 1 x M.2 Socket 3 connector | |
| 4 x SATA 6Gb/s connectors | |
| 1 x front panel header | |
| 1 x front panel audio header | |
| 1 x S/PDIF Out header | |
| 1 x CPU cooler LED strip/RGB LED strip header | |
| 1 x USB 3.1 Gen 1 header | |
| 2 x USB 2.0/1.1 headers | |
| 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only) | |
| 1 x serial port header | |
| 1 x Clear CMOS jumper | |
| Back Panel Connectors | |
| 1 x PS/2 keyboard/mouse port | |
| 1 x DVI-D port | |
| 1 x HDMI port | |
| 4 x USB 3.1 Gen 1 ports | |
| 4 x USB 2.0/1.1 ports | |
| 1 x RJ-45 port | |
| 3 x audio jacks | |
| I/O Controller | |
| iTEÆI/O Controller Chip | |
| H/W Monitoring | |
| Voltage detection | |
| Temperature detection | |
| Fan speed detection | |
| Overheating warning | |
| Fan fail warning | |
| Fan speed control | |
| * Whether the fan speed control function is supported will depend on the cooler you install. | |
| BIOS | |
| 1 x 128 Mbit flash | |
| Use of licensed AMI UEFI BIOS | |
| PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Unique Features | Support for APP Center |
| * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | |
| 3D OSD | |
| AutoGreen | |
| Cloud Station | |
| EasyTune | |
| Fast Boot | |
| Game Boost | |
| ON/OFF Charge | |
| RGB Fusion | |
| Smart Backup | |
| Smart Keyboard | |
| Smart TimeLock | |
| Smart HUD | |
| Smart Survey | |
| System Information Viewer | |
| USB Blocker | |
| V-Tuner | |
| Support for Q-Flash | |
| Support for Xpress Install | |
| Bundle Software | |
| NortonÆInternet Security (OEM version) | |
| cFosSpeed | |
| Operating System | |
| Support for Windows 10 64-bit | |
| Support for Windows 7 64-bit | |
| * To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU. | |
| * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7 | |
| Form Factor | |
| Micro ATX Form Factor; 24.4cm x 21.5cm |
| Featured | Yes |
|---|---|
| brand | Gigabyte |
