Features
Unbeatable EVGA 10 Year Warranty and unparalleled EVGA Customer Support
Fully Modular to reduce clutter and improve airflow
NVIDIA SLI & AMD Crossfire Ready
80 PLUS Platinum certified, with 92% (115VAC) / 94% (220VAC~240VAC) efficiency or higher under typical loads
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
100% Japanese Capacitors ensure long-term reliability
Active Clamp +DC to DC design for efficient operation
EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
Active Power Factor Correction
Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan.
DC-DC Converter improves 3.3V/5V stability
Specifications
ATX Cable
1x 600mm
EPS Cable
2x 700mm
PCIe Cable
2x 700mm, 2x 700mm, 850mm
SATA Cable
3x 550mm, 650mm, 750mm
Four-Pin Peripheral Cable
1x 550mm, 650mm, 750mm, 850mm
Floppy Adapter
1x 100mm
AC Power
1x 1500mm
Modular Cable Type
Full
Connector Quantity
24 Pin ATX
1x 24pin
EPS (CPU)
2x 8pin (4+4)
PCIe
6x 8pin (6+2)
SATA
9x
Four-Pin Peripheral
4x
Floppy
1x
Power Specs
AC Input
100-240V~, 12-5A, 60/50 Hz
Rail
+3.3V
+5V
+12V
+5Vsb
-12V
Max Output
24A
24A
70.8A
3A
0.5A
120W
850W
15W
6W
Total
850W
Additional Details
Operating Temperature
0° to 50° C
Japanese Capacitors
100%
ECO Mode
Yes
MTBF
100,000 Hours
Net Weight
6.70 lbs
Size
86mm (H) x 150mm (W) x 150mm (L)
Approvals
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHSCompliance with ErP Lot 3 2014 Requirement
Fan Size / Bearing
135mm Fluid Dynamic Bearing
