Unbeatable EVGA 10 Year Warranty and unparalleled EVGA Customer Support
80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
Fully Modular to reduce clutter and improve airflow
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
100% Japanese Capacitors ensure long-term reliability
EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
DC-DC Converter improves 3.3V/5V stability
135mm Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan
Specifications
ATX Cable
1x 600mm
EPS Cable
2x 750mm
PCIe Cable
4x 750mm, 2x 750mm, 900mm
SATA Cable
4x 550mm, 650mm, 750mm
Four-Pin Peripheral Cable
2x 550mm, 650mm, 750mm
Floppy Adapter
1x 100mm
AC Power
1x 1800mm
Modular Cable Type
Full
Molex to FDD
1x
Connector Quantity
24 Pin ATX
1x
EPS (CPU)
2x 8pin (4+4)
PCIe
8x 8pin (6+2)
SATA
12x
Four-Pin Peripheral
6x
Floppy
1x
Power Specs
AC Input
100-240V~, 15-8A, 60/50 Hz
Rail
+3.3V
+5V
+12V
+5Vsb
-12V
Max Output
24A
24A
108.3A
3.0A
0.5A
120W
1299.6W
15W
6W
Total
1300W
Additional Details
Operating Temperature
0° to 50° C
Japanese Capacitors
100%
ECO Mode
Yes
MTBF
100,000 Hours
Net Weight
8.20 lbs
Size
86mm (H) x 150mm (W) x 200mm (L)
Approvals
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHSCompliance with ErP Lot 3 2014 Requirement
