Features:
Line interactive UPS
Auto restart while AC is recovering
Double Boost
Automatic Voltage Regulation (AVR)
Wide Input Range
Microcontroller Based
Generator Compatible
No load Auto Shutdown at battery mode
Specifications:
Capacity
(VA/W)
600VA/360W
Input
Nominal voltage
220-240 VAC
Voltage range
140-300 VAC
Frequency
50/60 Hz
Plug type
3 Pin plug
Input Protection
Internal Fuse
Output
Voltage range (AC mode)
230VAC ± 10 %
Voltage range (Batt. mode)
230VAC ± 10 %
Frequency range (Batt. mode)
50/60Hz ±1%
Transfer time
4-8ms
Waveform
Simulated Sine Wave
No. of output sockets
3
Protections
Overload, Short Circuit, Over Discharge & Over Charge
Battery
Battery type
12V 7Ah x 1 nos
Charging current
1A
Recharge time
6-8h to charge 90% (after complete discharge)
Indicators
No. of LEDs
3 LED
AC mode
Green LED Glows
Battery mode
Orange LED blinks
Fault mode
Red LED Glow
Alarm
Battery mode
Beeping every 10 Seconds
Low battery
Beeping every 1 Second
Overload
Beeping every 0.5 second
Fault
Continuous beeping
Physical details
Product dimension (W x D x H)
101 x 280 x 142 mm
Net. weight
3.82 kg
Package dimension (WxDxH
326 x 142 x 213 mm
Environmental factors
Operational temperature
0-40⁰C
Noise level
< 45dB
Country of Origin
People's Republic of China
