Specifications:
Chipset
AMD B650
CPU
Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Memory
4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory Support
DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Memory Features
Supports Dual-Channel mode, non-ECC, un-buffered memory, AMD EXPOMax overclocking frequency: 1DPC 1R Max speed up to 7200+ MHz 1DPC 2R Max speed up to 6000+ MHz 2DPC 1R Max speed up to 6000+ MHz 2DPC 2R Max speed up to 5400+ MHz
Onboard Graphics
1x HDMI (HDMI 2.1, max resolution of 4K 60Hz),1x DisplayPort (DP 1.4, max resolution of 4K 60Hz)
Slots
1x PCI-E x16 slot Supports x16 (For Ryzen 9000 and 7000 Series processors) Supports x8 (For Ryzen 7 8700G and Ryzen 5 8600G processors) Supports x4 (For Ryzen 5 8500G processor)2x PCI-E x1 slotPCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset)PCI_E2 Gen PCIe 4.0 supports up to x16 (From CPU)PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
Audio
Realtek ALC897 Codec7.1-Channel High Definition Audio
Storage
2x M.2:M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devicesM.2_2 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices4x SATA 6G M2_2 supports PCIe 4.0 x2 speed when Ryzen 5 8500G is installed
RAID
Supports RAID 0, RAID 1, and RAID 10 for SATA storage devicesSupports RAID 0, RAID 1 for M.2 NVMe storage devices
USB
4x USB 2.0 (Front)4x USB 5Gbps Type A (Rear)2x USB 5Gbps Type A (Front)3x USB 10Gbps Type A (Rear)1x USB 10Gbps Type C (Rear)1x USB 10Gbps Type C (Front)
LAN
Realtek RTL8125BG 2.5Gbps LAN
Internal I/O
1x Power Connector(ATX_PWR)2x Power Connector(CPU_PWR)1x CPU Fan1x Pump Fan3x System Fan2x Front Panel (JFP)1x Chassis Intrusion (JCI)1x Front Audio (JAUD)1x Tuning Controller connector (JDASH)2x Addressable V2 RGB LED connector (JARGB_V2)2x RGB LED connector (JRGB)1x TPM pin header (Support TPM 2.0)4x USB 2.0 ports2x USB 5Gbps Type A ports1x USB 10Gbps Type C ports
Wireless LAN & Bluetooth
AMD Wi-Fi 6EWireless module pre-installed in the M.2 (Key-E) slotSupports MU-MIMO TX/RXSupports 20MHz, 40MHz, 80MHz, 160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bandsSupports 802.11 a/b/g/n/ac/axSupports Bluetooth 5.3**
LED Feature
4x EZ Debug LED
Back Panel Ports
DisplayPort2.5G LANUSB 3.2 Gen 2 10Gbps (Type-A)USB 3.2 Gen 1 5Gbps (Type-A)Wi-Fi / BluetoothFlash BIOS ButtonHDMIUSB 3.2 Gen 2 10Gbps (Type-A)USB 3.2 Gen 2 10Gbps (Type-C)Audio connectors
Operating System
Support for Windows 11 64-bit, Windows 10 64-bit
PCB Info
mATX243.84mm x 243.84mm
Warranty: 3 years
