Supports Intel Core Ultra Processors (Series 2)
DDR5 Compatible: 4*DIMMs with XMP Memory Module Support
Power Design: 16+1+2, 60A DrMOS
Thermals: VRM Thermal Armor and M.2 Thermal Guard
Connectivity: PCIe 5.0, 4x M.2 Slots, USB4, Front USB-C, Sensor Panel Link
DIY Friendly: PCIe EZ-Latch, EZ-Debug Zone
Networking: 2.5GbE LAN
5 Year Warranty
From the manufacturer:
Technical Details:
Platform
INTEL
Socket
LGA1851
CPU Type
Core Ultra
Chipset
Z890
Memory Speed
up to 9200
Max Memory Support
256 GB
Supported Memory Type
DDR5
Channel Supported
Dual Channel
Memory Feature
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modulesSupport CUDIMM memory module(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
Graphics Port
1 x USB4 USB Type-C Port, 1 x DisplayPort, 1 x front HDMI port
Expansion Slots
CPU:- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.Chipset:- 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1/2)
Wireless Networking
WiFi 7,Bluetooth 5.4
Back Panel I/O Ports
1 x USB4 USB Type-C port (DisplayPort (Note))2 x USB 3.2 Gen 2 Type-A ports (red)3 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports1 x DisplayPort (Note)2 x antenna connectors (2T2R)1 x RJ-45 port1 x optical S/PDIF Out connector2 x audio jacks(Note) Actual support may vary by CPU.
Internal I/O Connector
1 x 24-pin ATX main power connector2 x 8-pin ATX 12V power connectors1 x CPU fan header1 x CPU fan/water cooling pump header3 x system fan headers1 x system fan/water cooling pump header3 x addressable RGB Gen2 LED strip headers1 x RGB LED strip header4 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB Type-C header, with USB 3.2 Gen 2 support1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers2 x Thunderbolt add-in card connectors (For GIGABYTE Thunderbolt 5 add-in card only)1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)1 x HDMI port (Note)1 x power button1 x Q-Flash Plus button1 x reset button1 x reset jumper1 x Clear CMOS jumper(Note) Actual support may vary by CPU.
