GIGABYTE H610M H WIFI DDR4 MOTHERBOARD

Specifications




Category
Details


CPU
LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core™, Pentium Gold and Celeron ProcessorsL3 cache varies with CPU* Please refer to "CPU Support List" for more information.


Chipset
Intel H610 Express Chipset


Memory
Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s modules2 × DDR4 DIMM sockets, up to 64 GBDual-channel memory architectureSupports ECC Un-buffered DIMM (non-ECC mode)Supports non-ECC Un-buffered DIMMSupports Extreme Memory Profile (XMP)(See “Memory Support List” for details.)


Onboard Graphics
Integrated Intel HD Graphics1 × D-Sub port, max 1920×1200 @ 60 Hz1 × HDMI port, max 4096×2160 @ 60 Hz* HDMI 2.1 & HDCP 2.3 supported** Native HDMI 2.1 TMDS compatible ports(Graphics depend on CPU)


Audio
Realtek Audio CODECHigh Definition Audio2/4/5.1/7.1-channel7.1-channel configurable in audio software


LAN
Intel GbE LAN (1 Gbps/100 Mbps)


Expansion Slots
1 × PCI Express x16 (PCIe 4.0)1 × PCI Express x1 (PCIe 3.0)* Use PCIEX16 slot for GPU


Storage Interface
1 × M.2 Socket 3 (2260/2280, PCIe 3.0 x4/x2)4 × SATA 6Gb/s connectors


USB
Chipset:• 4 × USB 3.2 Gen 1 (2 rear, 2 internal)• 4 × USB 2.0/1.1 (rear)Chipset + USB Hub:• 4 × USB 2.0/1.1 (internal)


Internal I/O
1 × 24-pin ATX power1 × 8-pin ATX 12V1 × M.2 Socket 34 × SATA 6Gb/s1 × CPU fan2 × system fan1 × RGB LED header1 × front panel1 × front audio1 × USB 3.2 Gen 1 header2 × USB 2.0 headers1 × TPM header1 × serial header1 × Clear CMOS jumper


Back Panel
1 × PS/2 keyboard1 × PS/2 mouse1 × D-Sub1 × HDMI 2.02 × USB 3.2 Gen 14 × USB 2.01 × RJ-45 LAN3 × audio jacks


I/O Controller
iTE I/O Controller Chip


H/W Monitoring
Voltage, temperature, and fan speed detectionOverheating and fan fail warningsFan speed control (cooler dependent)


BIOS
1 × 256 Mbit flashAMI UEFI BIOSSupports PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0


Unique Features
APP Center (availability varies)@BIOSAmbient LEDEasyTuneSmart BackupSystem Information ViewerQ-FlashXpress Install


Bundled Software
Norton Internet Security (OEM)LAN bandwidth management software


Operating System
Windows 11 64-bitWindows 10 64-bit


Form Factor
Micro ATX, 23.0 cm × 21.5 cm
