Boost Clock: Up to 2520 MHzGame Clock: Up to 2070 MHz
Stream Processors
3584
Compute Units
56 CUs (3rd Gen RT + 2nd Gen AI Accelerators)
Infinity Cache
64MB
Ray Accelerators
56
AI Accelerators
112
Memory Size & Bus
16GB GDDR6 / 256-bit
Memory Clock
20 Gbps Effective
Max Displays
4
Max Resolution
HDMI®: 7680×4320DisplayPort„ 2.1a: 7680×4320
Interface
PCI-Express 5.0 x16
Outputs
2x HDMI®2x DisplayPort„ 2.1a
BIOS Support
UEFI
Game Index
4K
Power Consumption
220W Typical Board Power
Minimum PSU Requirement
650W
Power Connector
2 x 8-pin
Form Factor
2.5 slot, ATX
Dimensions
280mm (L) x 120.25mm (W) x 51.5mm (H)
Cooling System
Dual-X Cooling Technology
Fan Type
Two-Ball Bearing Fans
Sapphire Features
Honeywell PTM7950 TIM, AeroCurve Fan Blade, Free Flow, FrameDefense, Integrated Cooling Module, High TG Copper PCB, Optimized Composite Heatpipes, Metal Backplate, 12-Phase Digital Power Design, Fuse Protection, Intelligent Fan Control, Precision Fan Control
Software & Technologies
AMD HYPR-RX with AFMF 2, AMD FidelityFX„ Super Resolution 4 with AI Upscaling, AMD Fluid Motion Frames 2, AMD Radeon„ Anti-Lag 2, AMD Noise Suppression, AMD Freesync„, AMD Smart Technologies, Microsoft® DirectX® 12 Ultimate, AMD Software: Adrenalin Edition„
