Boost Clock: Up to 3060 MHzGame Clock: Up to 2520 MHz
Stream Processors
4096
Compute Units
64 CUs (3rd Gen RT + 2nd Gen AI Accelerators)
Infinity Cache
64MB
Ray Accelerators
64
AI Accelerators
128
Memory Size & Bus
16GB GDDR6 / 256-bit
Memory Clock
20 Gbps Effective
Max Displays
4
Max Resolution
HDMI®: 7680×4320DisplayPort„ 2.1a: 7680×4320
Interface
PCI-Express 5.0 x16
Outputs
2x HDMI®2x DisplayPort„ 2.1a
BIOS Support
UEFI
Game Index
4K
Power Consumption
330W Typical Board Power
Minimum PSU Requirement
750W
Power Connector
12V-2x6(H++) (Includes 3x8-pin power adapter)
Form Factor
3.2 slot, ATX
Dimensions
330.8mm (L) x 128.5mm (W) x 65.68mm (H)
Cooling System
Tri-X Cooling Technology
Fan Type
Two-Ball Bearing Fans
Sapphire Features
Quick Connect MagniPlate, STEALTH Hidden Power Cable, ARGB Light Bar, Cold Rolled Steel Frame, Honeywell PTM7950 TIM, Free Flow, FrameDefense, Optimized Composite Heatpipes, Fan Quick Connect, Premium 16-Phase Digital Power Design, Fuse Protection, Intelligent Fan Control, Precision Fan Control
Software & Technologies
AMD HYPR-RX with AFMF 2, AMD FidelityFX„ Super Resolution 4 with AI Upscaling, AMD Fluid Motion Frames 2, AMD Radeon„ Anti-Lag 2, AMD Noise Suppression, AMD Freesync„, AMD Smart Technologies, Microsoft® DirectX® 12 Ultimate, AMD Software: Adrenalin Edition„
Operating Systems
Linux®, Windows® 10 & 11 (64-bit required)
Bundled Accessories
L-Shape Support Bracket, 3-pin 5V ARGB Cable, Magnetic Backplate, 12V-2x6(H++) to PCI Express 3x8-pin Power Adapter
