Features:
Sequential read speed up to 5000 MB/s
Elevate everyday performance in Gaming, Business, Creative work with PCIe 4.0 x 4 and PCIe 5.0 x 2 compatibility
70% enhanced power efficiency supporting modern standby and longer battery life
Performance
Upgrade to faster sequential read speed up to 5,000 MB/s, reaching 43% faster than the previous model.
Power efficiency
70% enhanced power efficiency compared to the previous model, supporting Modern Standby and longer battery life.
Versatility
Elevate everyday performance in gaming, business, and creative work with PCIe® 4.0 x4 and PCIe® 5.0 x2 compatibility.
Speed that stays ahead
The 990 EVO offers enhanced sequential read/write speeds up to 5,000/4,200 MB/s, and random read/write speeds up to 700K/800K IOPS, reaching 43% faster than the 970 EVO Plus 2TB. Wait less for games and access big files quick.
Smart thermal solution
The 990 EVO's heat spreader label helps thermal control of the NAND chip. Samsung's cutting-edge thermal control algorithm, paired with Dynamic Thermal Guard, ensures both consistent and reliable performance. Keep your performance red-hot, not your drive.
Samsung Magician software
Make your SSD works like magic. Samsung Magician software's optimization tools ensure the best SSD performance. It's the safe and easy way to migrate all your data for a Samsung SSD upgrade. Protect valuable data, monitor drive health, and get the latest firmware updates.
Bringing innovations to life
For decades, Samsung’s NAND flash memory has powered groundbreaking technologies that have changed every part of our daily lives. This NAND flash technology also powers our consumer SSDs, making room for the next big push of innovation.
Specifications:
P/N
MZ-V9E2T0BW
Model
990 EVO NVMe M.2 SSD
Capacity
2TB
General Feature
Application
Client PCs
Capacity
2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor
M.2 (2280)
Interface
PCIe 4.0 x4 / 5.0 x2 NVMe 2.0
Dimension (WxHxD)
80 x 22 x 2.38 mm
Weight
Max 9.0g Weight
Storage Memory
Samsung V-NAND TLC
Controller
Samsung in-house Controller
Cache Memory
HMB(Host Memory Buffer)
Special Feature
TRIM Support
Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encryption Support
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support
Not supported
Device Sleep Mode Support
Yes
Performance
Sequential Read
Up to 5,000 MB/s * Performance may vary based on system hardware & configuration
Sequential Write
Up to 4,200 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32)
Up to 700,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)
Up to 800,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1)
Up to 20,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1)
Up to 90,000 IOPS * Performance may vary based on system hardware & configuration
Environment
Average Power Consumption (system level)
*Average: Read 5.5 W / Write 4.7 W* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)
Typical 60 mW * Actual power consumption may vary depending on system hardware & configuration
Power Consumption (Device Sleep)
Typical 5 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 - 70 ℃ Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
Accessories
Installation Kit
Not Available
Software
Management SW
Magician Software for SSD management
Warranty
5-year Limited Warranty or 1200 TBW Limited Warranty
Note
Features, Price, Specifications are subject to change without notice. Images used for representation purposes only
Storage
Category
Internal SSD
Series
990 EVO
Capacity
2TB
Form Factor
M.2 2280
NVMe
Yes
Interface
PCIe Gen4
Write Speed
Up to 4200 MB/s
Read Speed
Up to 5000 MB/s
TBW
1200
Warranty
5 Years
Note
Features, Price, Specifications are subject to change without notice. Images used for representation purposes only
