Features
Specifications
| General Feature | |
| Application | Client PCs |
| Capacity | 4,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
| Form Factor | 2.5 inch |
| Interface | SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface |
| Dimension (WxHxD) | 100 X 69.85 X 6.8 (mm) |
| Weight | Approx. 54.0g Weight |
| Storage Memory | Samsung V-NAND 4bit MLC |
| Controller | Samsung MKX Controller |
| Cache Memory | Samsung 4 GB Low Power DDR4 SDRAM |
| Special Feature | |
| TRIM Support | Yes |
| S.M.A.R.T Support | Yes |
| GC (Garbage Collection) | Auto Garbage Collection Algorithm |
| Encryption Support | AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive) |
| WWN Support | World Wide Name supported |
| Device Sleep Mode Support | Yes |
| Performance | |
| Sequential Read | Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration |
| Sequential Write | Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Read (4KB, QD32) | Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Write (4KB, QD32) | Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Read (4KB, QD1) | Up to 11,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Write (4KB, QD1) | Up to 35,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Environment | |
| Average Power Consumption (system level) | Average: 3.2 W *Maximum: 5.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration |
| Power consumption (Idle) | Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration |
| Allowable Voltage | 5V ± 5% Allowable voltage |
| Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
| Operating Temperature | 0 - 70 ? Operating Temperature |
| Shock | 1,500 G & 0.5 ms (Half sine) |
| Software | Management SW |
| Magician Software for SSD management | |
| Warranty | 3 Years |
| Featured | Yes |
|---|---|
| brand | Samsung |
