AMD Ryzen„ 7 7000 series 8-core/16-thread processor, burst up to 5.3 GHz AMD Radeon Graphics
CPU Architecture
64-bit x86
Graphic Processors
AMD Radeon„ Graphics
Floating Point Unit
Yes
Encryption Engine
Yes (AES-NI)
Hardware-accelerated Transcoding
Yes
System Memory
64 GB UDIMM DDR5 (2x 32 GB)
Maximum Memory
192 GB (4 x 48 GB)
Memory Slot
4 x UDIMM DDR5 Support optional ECC memory
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
30 x 2.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
2.5-inch SATA solid state drives
Hot-swappable
Yes
SSD Cache Acceleration Support
Yes
GPU pass-through
Yes
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2 (2.5G/1G/100M/10M)
10 Gigabit Ethernet Port
2 x 10GBASE-T (10G/5G/2.5G/1G/100M)
Wake on LAN (WOL)
Yes
Jumbo Frame
Yes
PCIe Slot
3 Slot 1: Gen 4 x 4 Slot 2: Gen 4 x 8 or Gen 4 x 4* Slot 3: Gen 4 x 4 *Slot 2 provides the width of PCIe Gen4 x8 when Slot 1 is not in use, and provides the width of PCIe Gen4 x4 when Slot 1 is in use. Card dimensions for PCIe slot 1：250 x 111.15 x 18.76 mm / 9.84 x 4.38 x 0.74 inches Card dimensions for PCIe slot 2：250 x 111.15 x 18.76 mm / 9.84 x 4.38 x 0.74 inches Card dimensions for PCIe slot 3：200 x 111.15 x 23.76 mm / 9.84 x 4.38 x 0.94 inches Wider cards can be installed if the next PCIe slot will not be used.
USB 3.2 Gen 2 (10Gbps) Port
2 x Type-A USB 3.2 Gen 2 10Gbps
Form Factor
2U Rackmount
LED Indicators
Power Status, SSD 1-30, Status, LAN, storage expansion port status
Buttons
Power, Reset
Dimensions (HxWxD)
88.3 × 442.6 × 485.2 mm Excludes ear hook and the protruding part of the Power Supply Unit.
