3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
2.5-inch bays: 2.5-inch SATA solid state drives
Hot-swappable
The following are not hot-swappable: M.2 SSDs, SSD cache drives, SSDs using PCIe expansion slots.
M.2 Slot
2 x M.2 2280 PCIe Gen 3 x4 slots
The M.2 SSD is not included as standard. M.2 SSD operations can easily generate excessive heat. It is recommended to install a heatsink (fromQNAPor a third-party provider) on the M.2 SSD.
SSD Cache Acceleration Support
SR-IOV
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2 (2.5G/1G/100M/10M)
10 Gigabit Ethernet Port
1 x 10GBASE-T (10G/5G/2.5G/1G/100M)
25 Gigabit Ethernet Port
Optional via PCIe expansion card
Wake on LAN (WOL)
Only the 2.5GbE port
Jumbo Frame
PCIe Slot
2 Slot 1: PCIe Gen 3 x4 Slot 2: PCIe Gen 3 x4
Card dimensions for PCIe slot 1：260 x 111.15 x 18.76 mm / 10.25 x 4.38 x 0.74 inches Card dimensions for PCIe slot 2：150 x 68.9 x 18.76 mm / 5.90 x 2.71 x 0.74 inches.
