| Chipset | INTEL Z790 |
| CPU SUPPORT | Supports 12th/13th Gen IntelĠ Coreī Processors, PentiumĠ Gold and CeleronĠ Processors |
| LGA 1700 |
| Memory | 4x DDR4, Maximum Memory Capacity 128GB |
| Memory Support 5333/5200/5066/5000/4800/4600/4533/4400/4266/4000/3866/3733/3600/3466/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133(By JEDCE & POR) |
| Max. overclocking frequency: |
| ƒ¯ 1DPC 1R Max speed up to 5333+ MHz |
| ƒ¯ 1DPC 2R Max speed up to 4800+ MHz |
| ƒ¯ 2DPC 1R Max speed up to 4400+ MHz |
| ƒ¯ 2DPC 2R Max speed up to 4000+ MHz |
| Supports IntelĠ XMP3.0 OC |
| Supports Dual-Controller Dual-Channel mode |
| Supports non-ECC, un-buffered memory |
| Onboard Graphics | 1x HDMIƒ´ |
| 1x DisplayPort |
| Support HDMIƒ´ 2.1, maximum resolution of 4K 60Hz |
| Support DP 1.4, maximum resolution of 8K 60Hz |
| EXPANSION SLOT | 2x PCI-E x16 slot |
| 1x PCI-E x1 slot |
| PCI_E1 PCIe 5.0 supports up to x16 (From CPU) |
| PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) |
| PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) |
| Storage | 5x M.2 slot |
| M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices |
| M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices |
| M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| M.2_4 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices |
| M.2_5 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices |
| 7x SATA 6G port |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices |
| USB | 4x USB 2.0 (Front) |
| 4x USB 3.2 Gen1 Type A (Rear) |
| 2x USB 3.2 Gen1 Type A (Front) |
| 4x USB 3.2 Gen2 Type A (Rear) |
| 1x USB 3.2 Gen2 Type C (Rear) |
| 1x USB 3.2 Gen2 Type C (Front) |
| 1x USB 3.2 Gen2x2 Type C (Rear) |
| LAN | IntelĠ 2.5Gbps LAN |
| WIRELESS / BLUETOOTH | IntelĠ Wi-Fi 6E |
| The Wireless module is pre-installed in the M.2 (Key-E) slot |
| Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz(160MHz) up to 2.4Gbps |
| Supports 802.11 a/ b/ g/ n/ ac/ ax |
| Supports BluetoothĠ 5.3, FIPS, FISMA |
| Audio | RealtekĠ ALC4080 Codec |
| 7.1-Channel USB High Performance Audio |
| Supports up to 32-Bit/384 kHz playback on front panel |
| Internal I/O | 1x Power Connector(ATX_PWR) |
| 2x Power Connector(CPU_PWR) |
| 1x CPU Fan |
| 1x Pump Fan |
| 6x System Fan |
| 2x Front Panel (JFP) |
| 1x Chassis Intrusion (JCI) |
| 1x Front Audio (JAUD) |
| 1x TBT connector (JTBT, supports RTD3) |
| 1x Tuning Controller connector(JDASH) |
| 3x Addressable V2 RGB LED connector (JARGB_V2) |
| 1x RGB LED connector(JRGB) |
| 1x TPM pin header(Support TPM 2.0) |
| 4x USB 2.0 |
| 2x USB 3.2 Gen1 Type A |
| 1x USB 3.2 Gen2 Type C |
| LED FEATURE | 4x EZ Debug LED |
| 1x EZ LED Control switch |
| BACK PANEL PORTS | Display Port |
| USB 3.2 Gen 1 5 Gbps (Type-A) |
| USB 3.2 Gen 2 10Gbps (Type-A) |
| 2.5G LAN |
| Wi-Fi / Bluetooth |
| Audio Connectors |
| HDMIƒ´ |
| Clear CMOS / Flash BIOS |
| USB 3.2 Gen 2 10Gbps (Type-A) |
| USB 3.2 Gen 2 10Gbps (Type-C) |
| USB 3.2 Gen 2x2 20Gbps (Type-C) |
| Optical S/PDIF Out |
| OPERATING SYSTEM | Support for WindowsĠ 11 64-bit, WindowsĠ 10 64-bit |
| PCB Dimension | ATX |
| 243.84mmx304.8mm |
| Warranty | 3 Years |
