AMD Ryzen 5 7520U (4C / 8T, 2.8 / 4.3GHz, 2MB L2 / 4MB L3)
16GB Soldered LPDDR5-5500
512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Integrated AMD Radeon 610M Graphics
Windows 11 Home Single Language, English
1Y Accidental Damage Protection Add On, 1Y Onsite upgrade from 1Y Depot/CCI delivery
PERFORMANCE
Processor
AMD Ryzen™ 5 7520U (4C / 8T, 2.8 / 4.3GHz, 2MB L2 / 4MB L3)
Graphics
Integrated AMD Radeon™ 610M Graphics
Chipset
AMD SoC Platform
Memory
16GB Soldered LPDDR5-5500
Memory Slots
Memory soldered to systemboard, no slots, dual-channel
Max Memory
16GB soldered memory, not upgradable
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
One M.2 PCIe® 3.0 x2 slot
Max Storage Support
One drive, up to 1TB M.2 2242 SSD
Optical
None
Card Reader
SD Card Reader
Audio Chip
High Definition (HD) Audio
Speakers
User-facing stereo speakers, 1.5W x2, optimized with Dolby Audio™
Microphone
2x, Array
Camera
HD 720p with Privacy Shutter
Battery
47Wh
Power Adapter
65W Round Tip (3-pin)
DESIGN
Display
15.6" FHD (1920x1080) TN 250nits Anti-glare
Touchscreen
None
Screen-to-Body Ratio
88% AAR (active area ratio)
Pen
Pen Not Supported
Keyboard
Backlit, English
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 69 x 104 mm (2.72 x 4.09 inches)
Dimensions (WxDxH)
359.3 x 235 x 17.9 mm (14.15 x 9.25 x 0.70 inches)
Weight
Starting at 1.62 kg (3.57 lbs)
Case Color
Arctic Grey
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Surface Treatment
IMR (In-Mold Decoration by Roller)
SOFTWARE
Operating System
Windows® 11 Home Single Language, English
Bundled Software
Microsoft® 365 Basic + Office Home 2024
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWAN
WWAN Not Supported
Ethernet
No Onboard Ethernet
Standard Ports
2x USB 3.2 Gen 1
1x USB-C® 3.2 Gen 1 (support data transfer, USB PD 45-65W and DisplayPort™ 1.2)
1x HDMI® 1.4
1x Headphone / microphone combo jack (3.5mm)
1x Card reader
1x Round tip power connector
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
No Fingerprint Reader
Other Security
Camera privacy shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
1Y Accidental Damage Protection Add On, 1Y Onsite upgrade from 1Y Depot/CCI delivery
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 9.0
EPEAT™ Silver Registered
ErP Lot 6/26
RoHS compliant
Mil-Spec Test
MIL-STD-810H military test passed (21 test items)
Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
MODEL INFORMATION
Model
82XQ0172IN
Machine Type
82XQ
Region
INDIA
Country/Region
India
TopSeller
Yes
EAN / UPC / JAN
199274136895
Announce Date
2025-12-04
End of Support
2029-04-01
Performance
Processor
Processor Family
AMD Athlon™ 10 Series Processor
AMD Athlon™ or AMD Ryzen™ 3 / 5 Processor
AMD Ryzen™ 3 / 5 10 Series Processor
Processor**
Processor Name
Cores
Threads
Base Frequency
Max Frequency
Cache
Processor Graphics
AMD Athlon™ Gold 7220U
2
4
2.4GHz
3.7GHz
1MB L2 / 4MB L3
AMD Radeon™ 610M
AMD Athlon™ Silver 10
2
2
2.4GHz
3.5GHz
1MB L2 / 2MB L3
AMD Radeon™ 610M
AMD Athlon™ Silver 7120U
2
2
2.4GHz
3.5GHz
1MB L2 / 2MB L3
AMD Radeon™ 610M
AMD Ryzen™ 3 30
4
8
2.4GHz
4.1GHz
2MB L2 / 4MB L3
AMD Radeon™ 610M
AMD Ryzen™ 3 7320U
4
8
2.4GHz
4.1GHz
2MB L2 / 4MB L3
AMD Radeon™ 610M
AMD Ryzen™ 5 40
4
8
2.8GHz
4.3GHz
2MB L2 / 4MB L3
AMD Radeon™ 610M
AMD Ryzen™ 5 7520U
4
8
2.8GHz
4.3GHz
2MB L2 / 4MB L3
AMD Radeon™ 610M
Operating System
Operating System**
Windows® 11 Pro
Windows® 11 Home
Windows® 11 Home Single Language
Windows® 11 Home Single Language in S mode
Windows® 11 Home in S mode
No preload operating system
Graphics
Graphics
Graphics
Type
Memory
Key Features
AMD Radeon™ 610M
Integrated
Shared
DirectX® 12
Monitor Support
Monitor Support
Supports up to 3 independent displays (native display and 2 external monitors via HDMI® and USB-C®) • HDMI® supports up to 4K@30Hz • USB-C® supports up to 4K@60Hz
Chipset
Chipset
AMD SoC (System on Chip) platform
Memory
Max Memory
4GB soldered memory, not upgradable
8GB soldered memory, not upgradable
16GB soldered memory, not upgradable
Memory Slots
Memory soldered to systemboard, no slots, dual-channel
Memory Type
LPDDR5-5500[1]
Notes:
1. Installed memory is actually LPDDR5-6400 but runs as LPDDR5-5500 due to platform limitation.
Storage
Max Storage Support[1]
One drive, up to 1TB M.2 2242 SSD
Storage Slot[2]
One M.2 PCIe® 3.0 x2 slot
Storage Type
Disk Type
Interface
Offering
M.2 2242 SSD
PCIe® NVMe®, PCIe® 3.0 x4[3]
128GB
M.2 2242 SSD
PCIe® NVMe®, PCIe® 4.0 x4[4]
256GB / 512GB / 1TB
Notes:
1. The storage capacity supported is based on the test results with current Lenovo® storage offerings.
2. The actual data transfer rate of the following PCIe® interface also depends on the capabilities of the connected PCIe® device. The listed values represent theoretical maximums. PCIe® 3.0 (x2 / x4): 2 GB/s (16 Gbps) / 4 GB/s (32 Gbps); PCIe® 4.0 (x2 / x4): 4 GB/s (32 Gbps) / 8 GB/s (64 Gbps); PCIe® 5.0 (x2 / x4): 8 GB/s (64 Gbps) / 16 GB/s (128 Gbps).
3. The SSD with PCIe® 3.0x4 is downgraded to closer to PCIe® 3.0x2 due to the AMD platform limitations.
4. The SSD with PCIe® 4.0x4 is downgraded to closer to PCIe® 3.0x2 due to the AMD platform limitations.
Removable Storage
Card Reader
SD card reader
Multi-Media
Audio Chip
High Definition (HD) Audio
Speakers
User-facing stereo speakers, 1.5W x2, optimized with Dolby Audio™
Microphone
Dual-microphone array
Camera**
FHD 1080p, with privacy shutter, fixed focus
HD 720p, with privacy shutter, fixed focus
Battery
Battery
47Wh Rechargeable Li-ion Battery, supports Rapid Charge Boost (get 2 hours of runtime with a 15-minute charge)
Max Battery Life[1]
MobileMark® 2018@200nits: 11 hr Local video (1080p) playback@150nits: 14 hr
Notes:
1. All battery life claims are approximate maximum and based on results using the MobileMark® 2014, MobileMark® 2018, MobileMark® 25, MobileMark® 30, JEITA 2.0, JEITA 3.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary depending on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.
Power Adapter
Power Adapter[1]
65W round tip (3-pin) AC adapter, 100-240V, 50-60Hz
No power adapter
Notes:
1. AC adapter offerings depend on the country.
Design
Display
Display**
Size
Resolution
Touch
Type
Brightness
Surface
Aspect Ratio
Contrast Ratio
Color Gamut
Viewing Angle (L/R/U/D)
15.6"
FHD (1920x1080)
Non-touch
TN
250nits
Anti-glare
16:9
400:1
45% NTSC
45° / 45° / 15° / 35°
15.6"
FHD (1920x1080)
Multi-touch
IPS[1]
300nits
Anti-glare
16:9
800:1
45% NTSC
85° / 85° / 85° / 85°
15.6"
FHD (1920x1080)
Non-touch
IPS[2]
300nits
Anti-glare
16:9
800:1
45% NTSC
85° / 85° / 85° / 85°
Touchscreen
On-cell multi-touch, supports 10-point touch
Non-touch
Screen-to-Body Ratio
88% AAR (active area ratio)
Notes:
1, 2. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
Input Device
Pen
No support
Keyboard
6-row, multimedia Fn keys, numeric keypad
Keyboard Backlight
LED backlight
Non-backlight
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 69 x 104 mm (2.72 x 4.09 inches)
Mechanical
Dimensions (WxDxH)[1] Click here to see dimension diagram
359.3 x 235 x 17.9 mm (14.15 x 9.25 x 0.70 inches)
Weight[2]
Starting at 1.62 kg (3.57 lbs)
Case Color**
Abyss blue
Arctic grey
Frost blue
Case Material
PC-ABS (top), PC-ABS (bottom)
Surface Treatment
IMR (in-mold decoration by roller)
Notes:
1. The system dimensions may vary depending on configurations.
2. The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
Connectivity
Network
WLAN + Bluetooth**[1]
Wi-Fi® 5, 802.11ac 2x2 Wi-Fi® + Bluetooth® 5.1, M.2 card
Wi-Fi® 6, 802.11ax 2x2 Wi-Fi® + Bluetooth® 5.2, M.2 card
WWAN
No support
Ethernet
No onboard Ethernet
Notes:
1. Wi-Fi® operation (including Wi-Fi® 6, Wi-Fi® 6E, Wi-Fi® 7, etc.) is subject to the regulatory requirements of each country. Bluetooth® may operate at a lower version than hardware design depending on the factors such as operating system, driver, etc.
Ports[1] Click here to see ports position
Standard Ports
2x USB 3.2 Gen 1
1x USB-C® 3.2 Gen 1 (support data transfer, USB PD 45-65W and DisplayPort™ 1.2)
1x HDMI® 1.4
1x Headphone / microphone combo jack (3.5mm)
1x Card reader
1x Round tip power connector
Notes:
1. The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed. USB 2.0: 480 Mbit/s; USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s; USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s; USB4® 20Gbps / USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s; USB4® 40Gbps (USB 40Gbps): 40 Gbit/s; Thunderbolt™ 3/4: 40 Gbit/s. Thunderbolt™ 5: 80 Gbit/s (bidirectional), up to 120 Gbit/s in bandwidth boost mode for video-intensive applications.
Security & Privacy
Security
Security Chip
Firmware TPM 2.0 integrated in SoC
Fingerprint Reader
Touch style fingerprint reader integrated in power button
No fingerprint reader
BIOS Security
Administrator password
Hard disk password
Power-on password
Other Security
Camera privacy shutter
Service
Warranty
Base Warranty**
1-year courier or carry-in service
1-year courier or carry-in with 2-year system board service (Korea only)
2-year (1-yr battery) courier or carry-in service
3-year (1-yr battery) courier or carry-in service
Accessories
Bundled Accessories
Bundled Accessories
Lenovo® 15.6" laptop casual toploader, polyester, black
Lenovo® 16" Laptop ECO Backpack B210 (black)
Lenovo® WL310 Bluetooth® Silent Mouse without battery
None[1]
Notes:
1. For more compatible accessory solutions, please visit Accessories for IdeaPad® Slim 3 15AMN8.
Operating Requirements
Operating Environment
Temperature[1]
At altitudes up to 2438 m (8,000 ft) - Operating: 5°C to 35°C (41°F to 95°F) - Storage: 5°C to 43°C (41°F to 109°F)
At altitudes above 2438 m (8,000 ft) - Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)
Relative Humidity
Operating: 8% to 95% at wet-bulb temperature 23°C (73°F)
Storage: 5% to 95% at wet-bulb temperature 27°C (81°F)
Altitude
Maximum altitude (without pressurization): 3048 m (10,000 ft)
Notes:
1. When you charge the battery, its temperature must be no lower than 10°C (50°F).
Certifications
Green Certifications[1]
Green Certifications[2]
ENERGY STAR® 9.0
EPEAT™ Silver Registered[3]
ErP Lot 6/26
RoHS compliant
Notes:
1. The items listed under the "Green Certifications" section may not only refer to certification but also registration or self-declaration. For ESG & regulatory compliance documents, please visit https://compliance.lenovo.com.
2. EPEAT™ registration and ENERGY STAR® certification are optional and only available on the models with preloaded OS. Please visit epeat.net and energystar.gov for more information.
3. EPEAT™ is registered where applicable, please visit epeat.net for registration status by country.
Other Certifications
Mil-Spec Test
MIL-STD-810H military test passed (21 test items)
Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
Feature with ** means that only one option listed under the feature can be configured on selected models. Please refer to the model configuration for specific information.
Lenovo reserves the right to change specifications or other product information without notice. Lenovo is not responsible for photographic or typographical errors. LENOVO PROVIDES THIS PUBLICATION "AS IS," WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions, therefore this disclaimer may not apply to you.
The specifications on this page may not be available in all regions, and may be changed or updated without notice.
