Up to Intel® Iris® Xe Graphics eligible (integrated)
Up to 16GB DDR4-3200, 1x Soldered + 1x SO-DIMM
Up to two drives, 1x 2.5" HDD + 1x M.2 SSD
Up to 14" (1920x1080) IPS 300nits
Operating System:
Operating System**
Windows® 11 Pro
Windows® 11 Home
Windows® 11 Home Single Language
Windows® 11 Home Single Language in S mode
Windows® 11 Home in S mode
No preload operating system
Graphics
Graphics**
Graphics
Type
Memory
Key Features
Intel® UHD Graphics
Integrated
Shared
DirectX® 12.1
Intel® Iris® Xe Graphics[1]
Integrated
Shared
DirectX® 12.1
Notes:
1. Intel Iris Xe Graphics capability requires system to be configured with dual-channel memory. On the system with single-channel memory, Intel Iris Xe Graphics will function as Intel UHD Graphics.
Monitor Support
Monitor Support
Supports up to 3 independent displays (native display and 2 external monitors via HDMI® and USB-C®) € HDMI® supports up to 4K@30Hz € USB-C® supports up to 4K@60Hz
Chipset
Chipset
Intel® SoC (System on Chip) platform
Memory
Max Memory[1]
Up to 4GB (4GB soldered + empty SO-DIMM slot) DDR4-3200 offering
Up to 16GB (8GB soldered + 8GB SO-DIMM) DDR4-3200 offering
Memory Slots
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Memory Type
DDR4-3200
Notes:
1. The max memory is based on the test results with current Lenovo® memory offerings.
Storage
Storage Support[1]
Models with 38Wh battery: up to two drives, 1x 2.5" HDD + 1x M.2 SSD € 2.5" HDD up to 1TB € M.2 2242 SSD up to 1TB € M.2 2280 SSD up to 1TB
Models with 45Wh battery: one drive, 1x M.2 SSD € M.2 2242 SSD up to 1TB € M.2 2280 SSD up to 1TB
Storage Slot
Models with 38Wh battery: one 2.5" drive slot + one M.2 slot € One 2.5" SATA HDD slot € One M.2 2280 PCIe® 4.0 x4 slot
Models with 45Wh battery: one M.2 slot € One M.2 2280 PCIe® 4.0 x4 slot
Storage Type***
Disk Type
Interface
Offering
2.5" SATA HDD
SATA 6Gb/s
1TB
M.2 2242 SSD
PCIe® NVMe®, PCIe® 3.0 x4
128GB / 256GB
M.2 2242 SSD
PCIe® NVMe®, PCIe® 4.0 x4
256GB / 512GB / 1TB
M.2 2280 SSD
PCIe® NVMe®, PCIe® 3.0 x4
512GB / 1TB
Notes:
1. The storage capacity supported is based on the test results with current Lenovo® storage offerings.
Removable Storage
Card Reader
SD card reader
Multi-Media
Audio Chip
High Definition (HD) Audio
Speakers
Stereo speakers, 1.5W x2, Dolby Audio„
Microphone
Dual-microphone array
Camera
HD 720p, with privacy shutter, fixed focus
Battery
Battery**
Integrated Li-Polymer 38Wh battery, supports Rapid Charge (charge up to 80% in 1hr)
Integrated Li-Polymer 45Wh battery, supports Rapid Charge Boost (get 2 hours of runtime with a 15-minute charge)
Max Battery Life[1]
Models with 38Wh battery: MobileMark® 2018: 4.8 hr Local video (1080p) playback@150nits: 7.7 hr
Models with 45Wh battery: MobileMark® 2018: 6.7 hr Local video (1080p) playback@150nits: 10 hr
Notes:
1. All battery life claims are approximate maximum and based on results using the MobileMark® 2014, MobileMark® 2018, MobileMark® 25, MobileMark® 30, JEITA 2.0, JEITA 3.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary depending on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.
Power Adapter
Power Adapter
65W round tip (3-pin) AC adapter, 100-240V, 50-60Hz
Design
Display
Display**
Size
Resolution
Touch
Type
Brightness
Surface
Aspect Ratio
Contrast Ratio
Color Gamut
Viewing Angle (L/R/U/D)
14"
FHD (1920x1080)
None
TN
250nits
Anti-glare
16:9
400:1
45% NTSC
45° / 45° / 15° / 35°
14"
FHD (1920x1080)
None
IPS[1]
300nits
Anti-glare
16:9
800:1
45% NTSC
85° / 85° / 85° / 85°
Touchscreen
Non-touch
Notes:
1. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
Input Device
Pen
No support
Keyboard
6-row, multimedia Fn keys
Keyboard Backlight
LED backlight
Non-backlight
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 62 x 104 mm (2.44 x 4.09 inches)
Mechanical
Dimensions (WxDxH)[1]
324.2 x 215.7 x 19.9 mm (12.76 x 8.49 x 0.78 inches)
Weight[2]
Starting at 1.43 kg (3.15 lbs)
Case Color**
Abyss blue
Arctic grey
Misty blue
Surface Treatment
IMR (in-mold decoration by roller)
Case Material
PC-ABS (top), PC-ABS (bottom)
Notes:
1. The system dimensions may vary depending on configurations.
2. The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
1. Wi-Fi 6 full features might be limited by country-level restrictions.
Ports[1]Click here to see ports position
Standard Ports
1x USB 2.0
1x USB 3.2 Gen 1
1x USB-C® 3.2 Gen 1 (support data transfer, Power Delivery and DisplayPort„ 1.2)
1x HDMI® 1.4b
1x Headphone / microphone combo jack (3.5mm)
1x Card reader
1x Power connector
Notes:
1. The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed. USB 2.0: 480 Mbit/s; USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s; USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s; USB4® 20Gbps / USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s; USB4® 40Gbps (USB 40Gbps): 40 Gbit/s; Thunderbolt„ 3/4: 40 Gbit/s.
Security & Privacy
Security
Security Chip
Firmware TPM 2.0 integrated in SoC
Fingerprint Reader
Touch style fingerprint reader integrated in power button
No fingerprint reader
BIOS Security
Administrator password
Hard disk password
Power-on password
Self-healing BIOS
Other Security
Camera privacy shutter
Service
Warranty
Base Warranty**
1-year courier or carry-in service
1-year courier or carry-in with 2-year system board service (Korea only)
2-year (1-yr battery) courier or carry-in service
3-year (1-yr battery) courier or carry-in service
Accessories
Bundled Accessories
Bundled Accessories[1]
Lenovo® 15.6" laptop casual toploader, polyester, black
