| Category | Specification |
|---|---|
| Hardware | |
| Audio Input | No |
| Audio Output | 1 - 3.5 mm AUX |
| Audio Switcher | No |
| Host Connector | 1 - USB-C® 3.2 Female |
| Ports | 1 - USB-C® PD 3.0 |
| 1 - HDMIâ„¢ Input | |
| 1 - 4K HDMIâ„¢ Output | |
| 1 - 3.5 mm audio jack | |
| 2 - USBâ„¢ Type-A (5Gbps) | |
| Power Source | Bus-powered or self-powered (USB-C® PD power) |
| Video Input | 1 - HDMIâ„¢ Female |
| Video Output | 1 - HDMIâ„¢ Female |
| Video Switcher | No |
| Warranty | 2 Year Limited |
| Performance | |
| Audio Channel | 2.1 via HDMIâ„¢ |
| Compressions | USBâ„¢ 2.0: MJPEG |
| Encode Format | MJPEG |
| HDR Supported | No |
| Headset | 2.1 Stereo |
| Max Display Refresh Rate | 30 Hz |
| Max Display Resolution | HDMIâ„¢ In: 3840 x 2160 |
| USB-C® Display: 3840 x 2160 | |
| Capture/Record: 1920 x 1080 | |
| Microphone | N/A |
| Power | |
| Input Current | 3A |
| Input Voltage | 20V |
| Output Current | 3A |
| Output Voltage | 20V |
| Power Consumption | ≤ 450 mA |
| Power Delivery | Up to 60W via USB-C® |
| Physical Specifications | |
| Cable Length | 11.8 in. (30 cm) |
| Color | Black |
| Enclosure Type | Plastic |
| Operating Humidity | < 80% non-condensing |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Product Depth | 3.79 in. (96.5 mm) |
| Product Height | 0.59 in. (15 mm) |
| Product Weight | 2.43 oz (69 g) |
| Product Width | 1.98 in. (50.5 mm) |
| Storage Humidity | < 85% non-condensing |
| Storage Temperature | 14 to 149°F (-10 to 65°C) |
| Package Contents | |
| 1 - JVA01 Video Capture USBâ„¢ Hub | |
| 1 - Quick Installation Guide (QIG) |
| Featured | Yes |
|---|---|
| brand | j5create |
