Designed to fit flush on the corner of the iPad Pro® 11" or 12.9" with or without a case
Easily add a HDMI„ video output, supporting resolution up to 4K at 60 Hz
Power and charge your laptop with up to 100W Power Delivery (3.0) pass-through charging and power your connected peripherals when it€™s used with a USB-C® power adapter
Right-angled host connector for your comfort
Includes 3 removable pads with soft rubber for secure and flexible mounting options
SuperSpeed USB„ ports: 1 x USB-C® and 1 x USB„ Type-A with up to 5 Gbps data transfer speed
Connect your headphone/speaker through the 3.5mm audio jack
Direct access to SD„ & microSD„ memory cards for data storage and transfer
Thunderbolt 3„ compatible
Specifications
Category
Specification
Hardware
Audio Supported
Yes
Host Connector
1 - USB-C® Male
Network Interface
N/A
Ports
1 - 4K HDMI„
1 - USB-C® 3.1 with Power Delivery 3.0 & Data Transfer
1 - USB„ 3.1 Type-A
1 - SD„ & microSD„ Memory Card Reader/Writer
1 - 3.5 mm Combo Audio Jack
Power Source
Bus-powered
Video Output
1 - HDMI„ Female
Warranty
2-Year Limited
Performance
Audio Channel
2.1 via HDMI„ / 3.5 mm Aux
Compatible Networks
N/A
Displays Supported
1
Max Data Transfer Rate
5 Gbps
Max Display Refresh Rate
60 Hz
Max Display Resolution
3840 x 2160
Power
Input Current
5A
Input Voltage
20V
Output Current
5A
Output Voltage
20V
Power Consumption
‰¤ 450 mA
Power Delivery
Up to 100W via USB-C®
Physical Specifications
Cable Length
8.3 in (211 mm)
Color
Silver, Black
Enclosure Type
Aluminum
Operating Humidity
< 85% non-condensing
Operating Temperature
32 to 118°F (0 to 48°C)
Product Depth
0.56 in (14.2 mm)
Product Height
5.33 in (135 mm)
Product Weight
3.17 oz (90 g)
Product Width
2 in (50.8 mm)
Storage Humidity
< 85% non-condensing
Storage Temperature
14 to 149°F (-10 to 65°C)
Package Contents
1 - JCD612 USB-C„ to 4K 60Hz HDMI„ Travel Dock for iPad Pro®
