Featuring all the ports you need, the 4K60 Elite USB-C® 10Gbps Travel Dock is equipped with an advanced USB-C® E-Mark chip for compatibility with USB4„, Thunderbolt„ 3, and Thunderbolt„ 4 hosts and devices.
It supports DisplayPort„ 1.4 allowing you to add a 4K 60Hz HDMI„ display and has a Gigabit Ethernet port for adding a wired network. It includes three USB„ SuperSpeed 10 Gbps ports (1 USB-C® and 2 USB„ Type-A) for peripheral connectivity or downstream charging. The USB-C® port also offers up to 100W of power pass-through when connected to a power adapter.
Features a 4K HDMI„ output, supporting video resolutions up to 3840 x 2160 at 60 Hz
Maximize your gaming experience with 1920 x 1080 @ 144 Hz refresh rate
Extending one display up to 3840 x 2160 @ 60, easily switch to a higher refresh rate of 2560 x 1440 @ 120 Hz via HDMI„ port to enjoy your gaming under Windows® OS
Three SuperSpeed USB„ 10Gbps downstream ports (1 USB-C® and 2 Type-A) to connect peripherals
Charge and power connected laptop and peripherals with 100W Power Delivery
Easily add a wired network connectivity with the Gigabit Ethernet port
Plug-and-play, no driver installation required
System Requirements
Available USB-C® port that supports DisplayPort„ alternate mode and USB„ Power Delivery 2.0 or 3.0 Please refer to the manufacturer of your computer for more information about your device
The host device must support DisplayPort„ 1.4 to achieve 4K resolution at 60 Hz. Example DisplayPort„ 1.4 devices are listed as follows, but not limited to:
Macbook Air® 13" 2019 or later
Macbook Pro® 15" 2017 or later
Macbook Pro® 16"
iPad Pro® 11"/12" 2018 or later
Surface„ Pro 7
Surface„ Laptop 3
Hardware
Warranty
2 Year Limited
Host Connector
1 - USB-C® Male
Video Output
1 - HDMI„ Female
Power Source
Bus-powered or self-powered
Network Interface
RJ45 (Gigabit Ethernet)
Audio Supported
Yes
Ports
€ 1 - USB-C® SuperSpeed 10Gbps with Power Delivery 3.0
€ 2 - USB„ Type-A SuperSpeed 10Gbps
€ 1 - 4K HDMI„
€ 1 - RJ45 Gigabit Ethernet
Performance
Maximum Display Resolution
3840 x 2160
Maximum Display Refresh Rate
3840 x 2160 @ 60 Hz
2560 x 1440 @ 120 Hz
1920 x 1080 @ 144 Hz
(Windows®)
Maximum Data Transfer Rate
10Gbps
Displays Supported
1
Compatible Networks
10/100/1000
Audio Channel
2.1 via HDMI„
Power
Power Delivery
Up to 100W via USB-C®
Power Consumption
‰¤ 400 mA
Input Current
Up to 5A
Input Voltage
Up to 20V
Output Current
Up to 4.5A
Output Voltage
Up to 20V
Physical Specifications
Color
Space Grey
Enclosure Type
Aluminum
Cable Length
5.9 in. (150 mm)
Product Height
0.62 in. (16 mm)
Product Width
4.33 in. (110 mm)
Product Depth
1.85 in. (47 mm)
Product Weight
3.06 oz (87g)
Storage Temperature
0 to 155°F (-17 to 68°C)
Storage Humidity
< 85% non-condensing
Operating Temperature
30 to 116°F (-1 to 41°C)
Operating Humidity
< 85% non-condensing
Special Notes
A 4K-capable display is required for obtaining the 3840 x 2160 resolution
If connected to a USB„ 2.0 host port, or if using a USB„ 2.0 host cable, performance may be limited
If connected to a DisplayPort„ 1.2 device performance will be limited to 3840 x 2160 at 30 Hz
The adapter can connect to a USB-C® port that doesn€™t support Power Delivery, but it will not pass power through the connected device
If you are using high-powered USB„ devices, attach a USB-C® power adapter to the power delivery port to ensure maximum performance. To avoid disruption, do not remove the power adapter while copying files.
We advise no more than one (1) bus-powered/portable external hard disk drive to be connected to the adapter at a time
