Total Cores: 24 # of Performance-cores: 8 # of Efficient-cores: 16 Total Threads: 32 Max Turbo Frequency: 6.00 GHz Intel® Thermal Velocity Boost Frequency: 6.00 GHz Intel® Turbo Boost Max Technology 3.0 Frequency: 5.80 GHz Performance-core Max Turbo Frequency: 5.40 GHz Efficient-core Max Turbo Frequency: 4.30 GHz Performance-core Base Frequency: 3.20 GHz Efficient-core Base Frequency: 2.40 GHz Cache: 36 MB Intel® Smart Cache Total L2 Cache: 32 MB Processor Base Power: 150 W Maximum Turbo Power: 253 W
Supplemental Information
Marketing Status: Launched Launch Date: Q1'23 Embedded Options Available: No Use Conditions: PC/Client/Tablet
Memory Specifications
Max Memory Size: 192 GB Memory Types: Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s Max # of Memory Channels: 2 Max Memory Bandwidth: 89.6 GB/s ECC Memory Supported: Yes
GPU Specifications
GPU Name: Intel® UHD Graphics 770 Graphics Base Frequency: 300 MHz Graphics Max Dynamic Frequency: 1.65 GHz Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1 Execution Units: 32 Max Resolution (HDMI): 4096 x 2160 @ 60Hz Max Resolution (DP): 7680 x 4320 @ 60Hz Max Resolution (eDP): 5120 x 3200 @ 120Hz DirectX Support: 12 OpenGL Support: 4.5 OpenCL Support: 3.0 Multi-Format Codec Engines: 2 Intel® Quick Sync Video: Yes Intel® Clear Video HD Technology: Yes # of Displays Supported: 4 Device ID: 0xA780
Expansion Options
Direct Media Interface (DMI) Revision: 4.0 Max # of DMI Lanes: 8 Scalability: 1S Only PCI Express Revision: 5.0 and 4.0 PCI Express Configurations: Up to 1x16+4, 2x8+4 Max # of PCI Express Lanes: 20
Package Specifications
Sockets Supported: FCLGA1700 Max CPU Configuration: 1 TJUNCTION: 100°C Max Operating Temperature: 100 °C
