| Essentials | |
| Product Collection | 11th Generation Intel Core‚ i9 Processors |
| Code Name | Products formerly Rocket Lake |
| Vertical Segment | Desktop |
| Processor Number | i9-11900 |
| Launch Date | Q1'21 |
| Lithography | 14 nm |
| Use Conditions | PC/Client/Tablet |
| Warranty | 3 Years |
| CPU Specifications | |
| Total Cores | 8 |
| Total Threads | 16 |
| Max Turbo Frequency | 5.20 GHz |
| Intel Thermal Velocity Boost Frequency | 5.20 GHz |
| Intel Turbo Boost Max Technology 3.0 Frequency | 5.10 GHz |
| Intel Turbo Boost Technology 2.0 Frequency | 5.00 GHz |
| Processor Base Frequency | 2.50 GHz |
| Cache | 16 MB Intel Smart Cache |
| Bus Speed | 8 GT/s |
| TDP | 65 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Datasheet | View now |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR4-3200 |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 50 GB/s |
| ECC Memory Supported | No |
| Processor Graphics | |
| Processor Graphics | Intel UHD Graphics 750 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.30 GHz |
| Graphics Video Max Memory | 64 GB |
| Execution Units | 32 |
| 4K Support | Yes | at 60Hz |
| Max Resolution (HDMI) | 4096x2160@60Hz |
| Max Resolution (DP) | 5120 x 3200 @60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 5120 x 3200 @60Hz |
| DirectX* Support | 12.1 |
| OpenGL* Support | 4.5 |
| Intel Quick Sync Video | Yes |
| Intel InTru 3D Technology | Yes |
| Intel Clear Video HD Technology | Yes |
| Intel Clear Video Technology | Yes |
| # of Displays Supported | 3 |
| Device ID | 0x4C8A |
| OpenCL* Support | 3 |
| Expansion Options | |
| Scalability | 1S Only |
| PCI Express Revision | 4 |
| PCI Express Configurations | Up to 1x16+1x4 | 2x8+1x4 | 1x8+3x4 |
| Max # of PCI Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | FCLGA1200 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2019C |
| Intel Thermal Velocity Boost Temperature | 70 ∞C |
| TJUNCTION | 100∞C |
| Package Size | 37.5 mm x 37.5 mm |
| Advanced Technologies | |
| Intel Gaussian & Neural Accelerator | 2 |
| Intel Deep Learning Boost (Intel DL Boost) | Yes |
| Intel Optane‚ Memory Supported | Yes |
| Intel Thermal Velocity Boost | Yes |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel Turbo Boost Technology | 2 |
| Intel vPro Platform Eligibility | Yes |
| Intel Hyper-Threading Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel SSE4.1 | Intel SSE4.2 | Intel AVX2 | Intel AVX-512 |
| Idle States | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Identity Protection Technology | Yes |
| Intel Stable IT Platform Program (SIPP) | Yes |
| Security & Reliability | |
| Intel AES New Instructions | Yes |
| Secure Key | Yes |
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel OS Guard | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel Boot Guard | Yes |
| Featured | Yes |
|---|---|
| brand | Intel |
