Powered by Radeon RX 7600
Integrated with 8GB GDDR6 128-bit memory interface
WINDFORCE cooling system
RGB Fusion
Protection metal back plate
CORE CLOCK
Boost Clock* : up to 2755 MHz (Reference card: 2655 MHz)Game Clock* : up to 2355 MHz (Reference card: 2250 MHz)
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, 5 composite copper heat pipes directly touch the GPU, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
GRAPHICS
Model
GV-R76GAMING-OC-8GD
Chipset
AMD RADEON
GPU
RX 7600
Engine Clock
Boost Clock : up to 2755 MHz (Reference card: 2655 MHz)Game Clock : up to 2355 MHz (Reference card: 2250 MHz)
PCI EXPRESS
4.0
MEMORY CLOCK
18 Gbps
MEMORY SIZE
8 GB
MEMORY INTERFACE
128-BIT
MEMORY TYPE
GDDR6
OpenGL
4.6
PORTS
HDMI,DisplayPort
DirectX
12 Ultimate
RESOLUTION
7680 x 4320
COOLER
Triple Fan
Max Display Support
4
Recommended PSU
550W
GPU CORE (CUDA CORE)
2048
POWER CONNECTORS
1 x 8-pin
WARRANTY
3 Years
NOTE**
Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only.
