CPU
- Supports Intel Core„ i7/i5/i3, Pentium, and Celeron processors in LGA1150 package.- L3 cache varies with CPU.Refer to "CPU Support List" for more details.
Chipset
Intel H81 Express Chipset
Memory
- 2 x DDR3 DIMM sockets, up to 16 GB system memory.- Dual channel memory architecture.- Supports DDR3 1600/1333 MHz, non-ECC, and Extreme Memory Profile (XMP) modules.32-bit Windows OS limitations apply for memory above 4 GB.
Onboard Graphics
Integrated Intel HD Graphics:- 1 x D-Sub port (1920x1200 max resolution).- 1 x HDMI port (4096x2160 max resolution, HDMI 1.4a).- Max shared memory: 1 GB.
LAN
Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps).
Expansion Slots
- 1 x PCI Express x16 slot (PCIe 2.0, x16).- 1 x PCI Express x1 slot (PCIe 2.0).
Storage Interface
- 1 x M.2 connector (SATA & PCIe 2.0 x4/x2 SSDs, shares bandwidth with SATA3 0).- 2 x SATA 6Gb/s connectors (SATA3).- 2 x SATA 3Gb/s connectors (SATA2).
USB
- 2 x USB 3.0/2.0 ports (rear panel).- 6 x USB 2.0/1.1 ports (2 rear, 4 internal headers).
Internal I/O Connectors
- 24-pin ATX power, 4-pin ATX 12V power.- 1 x M.2 connector, 2 x SATA 6Gb/s connectors, 2 x SATA 3Gb/s connectors.- CPU/system fan headers, front panel/audio headers.- 2 x USB 2.0/1.1 headers, serial port header, Clear CMOS jumper, TPM header.
Back Panel Connectors
- PS/2 mouse and keyboard ports.- 1 x D-Sub port, 1 x HDMI port.- 2 x USB 3.0/2.0 ports, 2 x USB 2.0/1.1 ports.- 1 x RJ-45 port, 3 x audio jacks.
I/O Controller
iTE I/O Controller Chip
H/W Monitoring
- Voltage, temperature, fan speed detection.- Overheating/fan fail warnings, fan speed control.Fan speed control depends on the fan installed.
BIOS
- 1 x 32 Mbit flash.- Licensed AMI UEFI BIOS (PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0).
Unique Features
- Q-Flash, APP Center (features vary by model).- Applications: @BIOS, EasyTune, EZ Setup, USB Blocker, Smart TimeLock, Smart Recovery 2, ON/OFF Charge.
Bundled Software
Norton Internet Security (OEM version), LAN bandwidth management software.
Operating System
Supports Windows 10/7.
Form Factor
Micro ATX, 23.0cm x 17.5cm.
Remarks
- Linux support depends on chipset vendors.- Some hardware/software vendors no longer provide drivers for older operating systems.
