LGA1700 socket: Supports Intel 14th, 13th, and 12th Gen Core„, Pentium Gold, and Celeron Processors L3 cache varies with CPU
Chipset
Intel H610 Express Chipset
Memory
2 x DDR5 DIMM sockets (up to 128 GB, 64 GB per DIMM) Dual-channel architecture 14th & 13th Gen i9/i7: DDR5 5600/5200/4800/4400 MT/s 13th Gen i5/i3 & 12th Gen: DDR5 4800/4400 MT/s Supports ECC Un-buffered DIMM (non-ECC mode) Supports non-ECC DIMM 1Rx8/2Rx8/1Rx16 Supports Extreme Memory Profile (XMP)
Onboard Graphics
Integrated Intel HD Graphics 1 x HDMI (4096×2160@60Hz, HDMI 2.1, HDCP 2.3) 1 x DisplayPort (4096×2304@60Hz, DP 1.2, HDCP 2.3) Depends on CPU support
Audio
Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel (configurable via software)
LAN
Realtek GbE LAN (1 Gbps / 100 Mbps / 10 Mbps)
Expansion Slots
CPU: 1 x PCIe 4.0 x16 slot Chipset: 1 x PCIe 3.0 x1 slot
Storage Interface
1 x M.2 (PCIe 3.0 x4/x2, type 2280/2260) 2 x SATA 6Gb/s connectors
USB Ports
Chipset: - 4 x USB 3.2 Gen 1 (2 rear, 2 internal) - 6 x USB 2.0/1.1 (4 rear, 2 internal)
Internal I/O
24-pin ATX power 8-pin ATX 12V power 1 x CPU fan header 1 x System fan header 1 x M.2 socket 2 x SATA connectors 1 x Front panel header 1 x Front audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0 header 1 x TPM header 1 x Clear CMOS jumper
Back Panel
1 x HDMI 1 x DisplayPort 2 x USB 3.2 Gen 1 4 x USB 2.0/1.1 1 x RJ-45 LAN 3 x Audio jacks
I/O Controller
iTE I/O Controller Chip
H/W Monitoring
Voltage, temperature, fan speed, water cooling flow rate detection Fan fail warning Fan speed control (depends on fan)
BIOS
128 Mbit flash AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
APP Center support (EasyTune, Smart Backup, System Info Viewer, @BIOS) Q-Flash support
Bundled Software
Norton Internet Security (OEM) LAN bandwidth management software (service discontinued)
