Supports AMD Ryzen 5000 Series/ Ryzen 5000 G-Series/ Ryzen 4000 G-Series and Ryzen 3000 and Ryzen 3000 G-Series Processors
Dual Channel ECC/ Non-ECC Unbuffered DDR4, 2 DIMMs
Integrated ARGB header and Q-Flash Plus button
PCIe Gen4.0 x4 M.2 with PCIe NVMe & SATA mode support
Fast Network: GbE LAN
8-Channel HD Audio with High Quality Audio Capacitors
Rear HDMI and DisplayPort for Multi-display Support
Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
GIGABYTE CONTROL CENTER (GCC), Simple and Easy Use
Technical details
Platform
AMD
Socket
AM4
Cpu Type
Ryzen 5000,Ryzen 4000,Ryzen 3000
Chipset
B550
Memory Speed
up to 5100
Max Memory Support
64 GB
Supported Memory Type
DDR4
Channel Supported
Dual Channel
Memory Feature
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE\'s website for more information.)
Graphics Port
1 x DisplayPort, 1 x HDMI
Expansion Slots
1 x PCI Express x16 slot, integrated in the CPU:AMD Ryzen 5000/3000 Series Processors support PCIe 4.0 x16 modeAMD Ryzen 5000 G/4000 G/3000 G Series Processors support PCIe 3.0 x16 modeChipset:1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Back Panel I/O Ports
2 x USB 2.0/1.1 ports1 x PS/2 keyboard/mouse port1 x DisplayPort*1 x HDMI port*1 x Q-Flash Plus button4 x USB 3.2 Gen 1 ports1 x RJ-45 port3 x audio jacks
Internal I/O Connector
1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers3 x addressable RGB Gen2 LED strip headers1 x RGB LED strip header1 x M.2 Socket 3 connector4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)1 x Clear CMOS jumper
