Form Factor: 2.5-inch internal SSD
Interface: SATA 6.0Gb/s
Total Capacity: 480GB*
Warranty: Limited 3-years
Sequential Read speed : up to 550 MB/s**
Sequential Write speed : up to 480 MB/s**
TRIM & S.M.A.R.T supported
Interface
SATA 6.0Gb/s
Form Factor
2.5-inch internal SSD
Total Capacity
480GB
NAND
NAND Flash
External DDR Cache
N/A
Sequential Read speed
Up to 550 MB/s
Sequential Write speed
Up to 480 MB/s
Random Read IOPS
up to 75k
Random Write IOPS
up to 70k
Dimension
69.85 x 7 x 100 mm
Mean time between failure (MTBF)
2M hours
Power Consumption (Active)
Average: R : 2240mW; W : 2610mW
Power Consumption (Idle)
170mW
Temperature (Operating)
0°C to 70°C
Temperature (Storage)
-40°C to 85°C
Warranty
1. Limited 3-years or 200TBW
2. Limited warranty based on 3 years or 200TBW, whichever comes first.*TBW (Terabyte Written):Terabytes Written is the total amount of data that can be written into an SSD before it is likely to fail.
3. The "percentage of SSD life" (SMART ID: E7 or A9) in SMART page of the "GIGABYTE SSD toolbox" program will be used as the determining criteria when the number is 0 means out of warranty. (A new unused product will show the percentage of 100.)
Note
• Test system configuration: configuration may vary by models; we will choose the latest platform for verification.
• Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
• Speeds based on internal testing. Actual performance may vary.
• 1GB = 1 billion bytes. Actual useable capacity may vary.
