Patented, exclusive FluxBarrier technology optimises motor efficiency and smoothness
Full Fanatec SDK support ensures compatibility out of the box for all major racing games
Standard Tuning Menu allows beginners to get started quickly without having to worry about settings
Advanced Tuning Menu allows enthusiasts to fine-tune the force feedback characteristics to suit their driving preferences
High-resolution (contactless) Hall-position-sensor, same as Podium Series
Steering axis made from carbon fibre-enhanced composite
Fanless: wheel base housing is made from aluminium (passive heat sink, core structural component) with composite end caps
Slip ring system (life-tested for thousands of hours) provides cable-free delivery of power and data between steering wheel and wheel base
QR2 quick release system
Motorsport-derived quick release
Tapered shape naturally ensures a tight fit
Carbon fiber-reinforced polyamide construction
Exchangeable
T-nut rail system on sides and bottom for easily adjustable hard-mounting
Table clamp included, supports 5 to 60 mm table thickness
Ports:
Power supply
USB-C to console / PC
Shifter 1
Shifter 2 (Sequential only)
Pedals
Handbrake
Front-mounted threaded inserts for Fanatec accessories (e.g. ClubSport Static Shifter Paddles, available separately). Not intended for front-mounting the wheel base to a sim racing chassis/cockpit.
Steering wheel for Gran Turismo DD Pro:
Designed by Polyphony Digital
Tactile rubber grip with blue centre stripe
Compact 280 mm diameter and light weight for crisp response
Diffused RevLED strip (yellow, red, and blue LEDs)
White OLED display for Tuning Menu access and telemetry output (where supported)
5-way directional stick for menu navigation
Four additional 5-way directional sticks
Ergonomic shifter paddles
11 buttons optimised for the PlayStation® interface
Fiberglass-reinforced plastic construction
QR2 Lite Wheel-Side preinstalled
Pedals for Gran Turismo DD Pro:
Two-pedal set (throttle and brake), upgradeable to three pedals (upgrade kits sold separately)
All-metal construction (excluding pedal faces). Pedals are made from heavy steel, which helps to prevent the set from sliding on the floor (if not hard-mounted to a rig)
Contactless Hall sensors (12-bit) on both brake and throttle for high precision and durability
Brake pedal spring is stiffer than throttle pedal spring, PU foam damper adds additional resistance for progressive braking feel
Upgrade to a three-pedal configuration with Clutch Kit or Load Cell Kit (sold separately)
CSL Pedals Clutch Kit provides a third pedal for the lowest price
CSL Pedals Load Cell Kit also provides a third pedal, and upgrades the brake and electronics
Pedal position can be adjusted sideways along heel rest
Height-adjustable pedal faces
Modular design means inverted mounting to a rig is possible
Vertical rear plates allow pedals to be easily braced against a wall or other vertical surface
Pearl chrome plating on pedal bases and arms
Black powder coating on heel rest
Pedals connect directly to Gran Turismo DD Pro Wheel Base
Compatibilities
Peripherals
The Gran Turismo DD Pro Wheel Base is compatible with:
All Fanatec Podium Steering Wheels (depending on the quick release)
All Fanatec ClubSport Steering Wheels (depending on the quick release)
All Fanatec CSL Steering Wheels (depending on the quick release)
All Fanatec Pedals (adapter cables might be required on pedals without RJ12 connection)
All Fanatec Shifters
All Fanatec Handbrakes
Boost Kit 180
All Fanatec Cockpits
CSL DD Table Clamp
ClubSport Table Clamp V2
Podium Mounting Brackets (the Gran Turismo DD Pro includes M6 T-nuts for side-mounting; the Podium Mounting Brackets require the use of M6 bolts and washers)
Please note: Compatibility with all peripherals is tested by Fanatec, but not tested nor endorsed by Sony Interactive Entertainment Inc.
Depending on the installed quick release, the steering wheel for Gran Turismo® DD Pro is compatible with:
PODIUM Wheel Base DD1 (QR1 Wheel-Side required*)
PODIUM Wheel Base DD2 (QR1 Wheel-Side required*)
PODIUM Wheel Base DD1 PS4™ (QR1 Wheel-Side required*)
ClubSport Wheel Base V2 (without four additional D-sticks)
ClubSport Wheel Base V2.5
CSL Elite Wheel Base (without four additional D-sticks)
CSL Elite Wheel Base V1.1 (without four additional D-sticks)
CSL Elite Wheel Base + - officially licensed for PS4™
CSL DD Wheel Base
Gran Turismo DD Pro Wheel Base
Note: The steering wheel for Gran Turismo DD Pro does NOT enable PlayStation® compatibility when used with a non-PlayStation-licensed wheel base. A PlayStation-licensed wheel base (such as the Gran Turismo DD Pro Wheel Base) is required for use on PS5® and PS4®.
The pedals for Gran Turismo DD Pro is compatible with:
CSR / CSR Elite Wheel Base
All CSL Elite Wheel Bases
All ClubSport Wheel Bases
All Podium Wheel Bases
GT DD Pro Wheel Base
CSL DD Wheel Base
Please refer to the Gran Turismo DD Pro manual for full pedal compatibility information.
Platforms
This product is compatible with all PS5® and PS4® consoles.
This product is compatible with PC on all major racing games.
Other platforms: Compatibility with other platforms depends on the used steering wheel. For more information, please check the product page of the steering wheel you plan to use.
Please note: PC and other platform compatibility is tested by Fanatec, but not tested nor endorsed by Sony Interactive Entertainment Inc.
What Included
