The open-framed design supports up to 360mm water cooling radiators, a 190mm CPU cooler and 9 fans: the ability to optimize your cooling system with unparalleled freedom protects your rig from overheating during even the most intense sessions.
Technical Details
Product Name
Cratus
Model No.
CGR-5LMSB
Case Form Factor
Mid Tower
Motherboard Type
Mini ITX / Micro ATX / ATX / CEB / E-ATX
Dimensions (WxHxD)
283 x 636 x 635 (mm)11.1 x 25 x 25 (in)
I/O Panel
Type C Gen 2 (Key A 20-pin connector) x 1, USB 3.0 x 4,4 Pole Headset Audio Jack x1, RGB Button
3.5" Drive Bay
2
2.5" Drive Bay
3 + 2 (converted from 3.5" drive bays) / (3 SSD trays included)
Expansion Slots
Horizontal : 7 / Vertical : 4 (install with a vertical bracket in the accessory kit)
Vertical GPU Support
Yes
Cooling Fan Support
Front
120mm x 2 / 140mm x 2
Top
120mm x 3 / 140mm x 2
M/B Side
120mm x 3
Rear
120mm x 1
Pre-installed Fans
Front
120mm ARGB fan x 2
Rear
120mm ARGB fan x 1
Speed
1000 ± 100 RPM
Connector
5V 3 Pin (ARGB) / 3 Pin (Fan)
Maximun Number of Fans
9 Max.
Water Cooling Support
Front
*280mm / 240mm / 140mm / 120mm
Top
360mm / 280mm / 240mm / 140mm / 120mm
M/B Side
360mm / 240mm / 120mm
Transparent Panel
Tempered Glass x 4
Onboard Lighting System
Yes
RGB Sync with M/B
Yes
Max. Graphics Card Length
460 (mm) / 18.1 (in) without fans and radiator at M/B side325 (mm) / 12.8 (in) with fans and radiator at M/B side
