Model Number | MCB-CM694-KN5N-S00 (Steel) |
Series | MasterBox Series |
Size | Mid Tower |
Color(s) | Black |
Materials | Steel, Plastic, Tempered Glass, Mesh |
Dimensions (L x W x H) | Steel: 493mm x 220mm x 506mm (incl. Protrusions), Steel: 482mm x 220mm x 477mm (excl. Protrusions) |
Motherboard Support | Mini ITX, Micro ATX, ATX, E-ATX |
Expansion Slots | 7 |
5.25" Drive Bays | 2 |
2.5" / 3.5" Drive Bays (Combo) | 6 (3x drive cages) |
2.5" Drive Bays | 8 (2 + 6 combo) |
I/O Panel | 2x USB 3.0 Type A, 1x USB 3.1 Type-C, 1x 3.5mm Headset Jack (Audio+Mic) |
Pre-installed Fans - Front | 2x 120mm Fan (1200 RPM ± 200 RPM, 3 pin connector) |
Pre-installed Fans - Rear | 1x 120mm fan (1200 RPM ± 200 RPM, 3 pin connector) |
Fan Support - Front | 3x 120mm / 2x 140mm (wo/ODD), 2x 120mm / 2x 140mm (w/ODD) |
Fan Support - Top | 3x 120mm, 2x 140mm |
Fan Support - Rear | 1x 120mm |
Radiator Support - Front | 120mm*, 140mm*, 240mm*, 280mm**, 360mm** (*remove 2 out of 3 drive cages) (**remove 2 out of 3 drive cages & ODD cage) |
Radiator Support - Top | 120mm, 140mm, 240mm, 280mm, 360mm, (mount radiator below the bracket & fans above the bracket for maximum compatibility) |
Radiator Support - Rear | 120mm |
Clearance - CPU Cooler | 171mm |
Clearance - GFX | 410mm/16.1", 350mm (with stabilizer), 280mm (with stabilizer + drive cage) |
Clearance - PSU | 276mm, 160mm (drive cage rear position) |
Power Supply Support | Bottom Mount, ATX PS2 |
Dust Filters | Top, Front, Bottom |
Cable Routing | 27-29mm |
Warranty | 2 Years |
*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
| Featured | Yes |
|---|---|
| brand | Cooler Master |
