Features
Compact and efficient, the LBP6030w is designed to help save space and perform high-speed print jobs, with low energy consumption. Set up wireless printing effortlessly with the WPS button.
Sleep mode and Auto Shutdown feature
Print speed (A4): 18 pages per minute
Canon Mobile Printing enabled
On Demand Fixing Technology:
Canon's proprietary technology On-Demand Fixing consume less power and warm up quickly compared to the conventional fusing roller designs, enabling a fast warm up time and quick first print.
Mobile Printing Solutions:
With Canonís latest mobile business solution, you can print documents, photos, web pages and emails all with just one app. Click here to find out more!
Minimal Maintenance
The Canon all-in-one toner cartridge 925 integrates the photosensitive drum, cleaning unit and toner reservoir in one compact package, saving costs and making cartridge replacements easy.
Low Energy Consumption:
The printer can be configured to enter sleep mode and auto shutdown after it remains idle for a specified length of time, consuming less energy. With a low Energy Star Typical Electricity Consumption value of 0.48kWh/week, it is easy to be kind to the environment while saving cost.
UFR II LT:
With Canon UFR II LT print language, the printer takes full advantage of the PC's processing power. UFR II LT effectively removes the need for expensive memory upgrades on the printer.
WPS Button:
The LBP6030w comes with the WPS button located on the printer. Set up a Wi-Fi connection for wireless printing, with just one-touch of the WPS button on the printer and router.
Specifications
Print
Printing Method
Monochrome Laser Beam Printing
Print Speed
A4:
18 pages per minute
Letter:
19 pages per minute
Print Resolution
600 x 600dpi
Print Quality with Image Refinement Quality
2 400 (equivalent) ◊ 600dpi
Warm-Up Time
(From Power On)
10s
First Printout Time (FPOT)
7.8s
Recovery Time
(From Sleep Mode)
1s
Print Language
UFR II LT
Paper Handling
Paper Input (Standard)
150 sheets (based on 80g/m2)
Paper Output
100 sheets (face down)
(based on 80g/m2)
Paper Size
A4, B5, A5, Legal*1, Letter, Executive, 16K, Envelope COM10, Envelope Monarch, Envelope C5, Envelope DL
Custom: Width 76.2 to 215.9mm x Length 188 to 355.6mm
Paper Weight
60 to 163g/m2
Paper Type
Plain paper, Heavy Paper, Transparency, Label, Envelope.
Connectivity and Software
USB Interface
USB 2.0 High Speed
Network Interface
Wi-Fi 802.11b/g/n (WPS Easy Set Up)
Network Protocol
Print:
LPD, RAW, WSD-Print
Management:
SNMPv1, SNMPv3, SLP
TCP/IP Application Services: WINS (IPv4), DHCP, BOOTP, RARP, DHCPv6 (IPv6), Auto IP, mDNS, DNS, DDNS
Network Security
WEP, WPA-PSK(TKIP/AES-CCMP), WPA2-PSK(TKIP/AES-CCMP)
Mobile Print
Canon Mobile Printing
Compatible Operating Systems*2
Win 8.1 (32 / 64bit), Win 8 (32 / 64bit), Windows 7 (32 / 64-bit), Windows Vista (32 / 64-bit), Windows XP (32 / 64-bit), Windows Server 2012 (32 / 64bit), Windows Server 2012 R2 (64 bit), Windows Server 2008 (32 / 64bit), Windows Server 2008 R2 (64bit), Windows Server 2003 (32 / 64bit),
Mac OS 10.6.x~10.9*3, Linux*3, Citrix
General Specification
Operation Panel
3 LED indicators, 3 Operation Key
Device Memory
32MB
Dimensions (W x D x H)
364 x 249 x 199mm
Weight
5.0kg (Without Cartridge)
Noise Level*4
During Operation:
Sound Power Level:
6.53dB
Sound Pressure Level:
49.3dB
During Standby:
Sound Power Level:
Inaudible*5
Sound Pressure Level:
Inaudible*5
Power Consumption
Maximum 840W
Average Power Consumption
During Operation:
320W
During Standby:
1.8W (USB connection)
2.8W (Wireless connection)
During Sleep:
0.8 W (USB connection)
1.6W (Wireless connection)
Energy Star TEC
(Typical Electricity Consumption)
0.48kWh/week
Operating Environment
Temperature:
10~30∞C
Humidity:
20% to 80% RH (no condensation)
Power Requirement
220 - 240V (±10%), 50 / 60Hz (±2Hz)
Toner Cartridge*6
Cartridge 925:
1 600 pages
Monthly Duty Cycle*7
5 000 pages
Recommended Monthly Print Volume
200 - 800 pages
