Specifications
Intel Specification
ATX12V
Dimensions
16 x 15 x 8.6 Centimeter
Efficiency
80Plus Gold
Protection Features
OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials
ROHS
AC Input Range
100-240Vac
Thermal Features
ROG Thermal Solution
DC Output Voltage
+3.3V +5V +12V -12V +5Vsb
Maximum Load
25A 25A 83A 0.3A 3A
Combined Load
125W 996W 3.6W 15W
Total Output
1000W
Connectors
MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 6+2-pin x 6
SATA x 8 PERIPHERAL x 6
Package Contents
Power Cord x 1
Motherboard Power Cable x 1 (610mm)
CPU Cable 1000mm x 2 (1000mm)
PCI-E Cable x 3 (675mm)
SATA Cable x 2 (810mm/860mm)
Peripheral x 2 (450mm)
ROG badge x 2
ROG logo magnet x 1
ROG label x 3
*MB/ CPU/ PCI-E cables come with embedded capacitors in the middle.
Weight
1.885 Kg
Warranty
10 Years
*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
