Features
AMD AM4 socket: Ready for 2nd, and 3rd Gen AMD Ryzenô processors and up to two M.2 drives, USB 3.2 Gen2, and AMD StoreMI to maximize connectivity and speed.
Comprehensive thermal design: Integrated Crosschill EK III, active chipset heatsink, M.2 aluminum heatsink, and ROG Cooling Zone.
Robust power delivery: Designed power solution with 14+2 IR3555 PowIRstages, ProCool II power connectors, microfine alloy chokes and 10K Japanese-made black metallic capacitors
High-performance networking: On-board Wi-Fi 6 (802.11ax) with MU-MIMO support, 5G and Gigabit Ethernet courtesy of Aquantia and Intel, both with ASUS LANGuard protection and support for GameFirst V software.
5-Way Optimization: Automated system-wide tuning, providing overclocking and cooling profiles that are tailor made for your rig.
DIY Friendly Design: Pre-mounted I/O shield, ASUS SafeSlot, BIOS flashback and premium components for maximum endurance.
Unmatched personalization: ASUS-exclusive Aura Sync RGB lighting, including RGB headers and addressable Gen 2 RGB headers
Industry-leading ROG audio: SupremeFX S1220 and ESSÆ ES9023P for enthusiast-grade audio performance driven by Japanese capacitors.
Specifications
CPU
AMD AM4 Socket 3rd and 2nd AMD Ryzenô/2nd and 1st Gen AMD Ryzenô with Radeonô Vega Graphics Processors
Chipset
AMD X570
Memory
AMD X570
4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Memory
4 x DIMM, Max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Memory
3rd Gen AMD Ryzenô Processors
2nd Gen AMD Ryzenô Processors
2nd and 1st Gen AMD Ryzenô with Radeonô Vega Graphics Processors
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
4 x DIMM, Max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Memory
Multi-GPU Support
3rd and 2nd Gen AMD Ryzenô Processors
Supports AMD 3-Way CrossFireXô Technology
Supports AMD 2-Way CrossFireXô Technology
Supports NVIDIAÆ 2-Way SLIÆ Technology
Expansion Slots
2 x PCIe 4.0 x16 (x16 or dual x8)
2 x PCIe 3.0 x16 (x16 or dual x8)
1 x PCIe 4.0 x16 (x4 mode)
1 x PCIe 4.0 x1
1 x PCIe 3.0 x16 (x8 mode)
AMD X570 chipset
Storage
1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
8 x SATA 6Gb/s port(s),
3rd Gen AMD Ryzenô Processors :
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
2nd Gen AMD Ryzenô/2nd and 1st Gen AMD Ryzenô with Radeonô Vega Graphics Processors :
AMD X570 chipset :
1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
Support Raid 0, 1, 10
LAN
IntelÆ I211-AT
Aquantia AQC111C 5G LAN
ROG GameFirst V Technology
ASUS LAN Guard
Wireless Data Network
Up to 2.4Gbps transfer speed
Supports channel bandwidth: HT20/HT40/HT80/HT160
2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)withMU-MIMO supportsdualfrequency band 2.4/5GHz
Bluetooth
BluetoothÆ 5.0
Audio
ROG SupremeFX8-Channel High Definition Audio CODEC S1220
- Supports : Multi-streaming, Front Panel Jack-retasking
- High quality120dBSNR stereo playback outputand113dBSNR recording input
- SupremeFX Shielding Technology
- ESSÆ ES9023P
- Supports up to 32-Bit/192kHz playback *
- Gold-plated jacks
- Optical S/PDIF out port(s) at back panel
- Sonic Radar III
- Sonic Studio III + Sonic Studio Link
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
Audio Feature :
USB Ports
4 x USB 3.2 Gen 2 port(s) (4 at back panel, red, Type-A)
4 x USB 3.2 Gen 1 port(s) (4 at back panel, red, Type-A)
1 x USB 3.2 Gen 2 front panel connector port(s)
4 x USB 3.2 Gen 2 port(s) (3 at back panel, red, Type-A, 1 x Type-C)
8 x USB 3.2 Gen 1 port(s) (4 at back panel, blue, 4 at mid-board)
4 x USB 2.0 port(s)
3rd Gen AMD RyzenTM Processors :
2nd Gen AMD RyzenTM/2nd and 1st Gen AMD Ryzenô with Radeonô Vega Graphics Processors :
AMD X570 chipset :
ROG Exclusive Features
USB BIOS FlashBackô
ROG RGB Armor
Start Button
Reset Button
ROG Aura
Extreme Engine Digi+ :
- IR3555 PoweIRstageÆ
- MicroFine Alloy Chokes
- 10K Black Metallic Capacitors
ROG Extreme OC kit :
- Safe Boot button
- Slow Mode
- LN2 Mode
UEFI BIOS features :
- Tweakers¥ Paradise
- ROG SSD Secure Erase
- Graphic Card Information Preview
Crosschill EK III
ROG Patented Pre-mounted I/O Shield
ROG Exclusive Software
- Mem Tweakit
- RAMCache III
- RAMDisk
- CPU-Z
- GameFirst V
- Overwolf
Special Features
- USB BIOS FlashBackô
- BIOS FlashBackô Button
ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 :
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, and Turbo App
Gamer¥s Guardian:
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio,and USB ports
ASUS SafeSlot - Protect your graphics card Investment
LiveDash OLED
AURA :
- Aura Lighting Control
- Aura RGB Strip Headers
- Addressable Gen 2 Header
ASUS Exclusive Features :
- AI Suite 3
- Ai Charger
- ASUS CrashFree BIOS 3
- Armoury Crate
- Pre-mounted I/O Shield
- ASUS NODE: hardware control interface
- Clear CMOS Button
ASUS Q-Design :
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-DIMM
- ASUS Q-Connector
Back I/O Ports
1 x USB BIOS FlashBackô Button(s)
1 x Optical S/PDIF out
1 x Clear CMOS button(s)
1 x ASUS Wi-Fi Module
1 x Gold-plated audio jacks
4 x USB 3.2 Gen 1 (up to 5Gbps) ports
8 x USB 3.2 Gen 2 (up to 10Gbps) ports ()
Anti-surge LAN (RJ45) port
1 x AQC-111C 5G LAN port
Internal I/O Ports
2 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 4 USB ports
1 x PCH_FAN
2 x Aura RGB Strip Header(s)
2 x Addressable Gen 2 header(s)
1 x M.2 Socket 3 with M key, type 2242/2260 storage devices support (both SATA & PCIE mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode)
8 x SATA 6Gb/s connector(s)
1 x CPU Fan connector(s)
1 x CPU OPT Fan connector(s)
3 x Chassis Fan connector(s)
1 x Optional Fan connector(s)
1 x AIO_PUMP connector
1 x H_AMP fan connector
1 x W_PUMP+ connector
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x 4-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x Slow Mode switch(es)
1 x LN2 Mode header(s)
1 x Power-on button(s)
1 x Reset button(s)
1 x Node Connector(s)
1 x Safe Boot button
1 x ReTry button
1 x System panel connector
1 x W_IN header
1 x W_OUT header
1 x W_FLOW header
1 x Thermal sensor connector
1 x Speaker connector
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x USB 3.2 Gen 2 (up to 10Gbps) connector
Accessories
1 x ROG logo plate sticker
4 x SATA power cable
1 x ROG big sticker
1 x Q-Connector
1 x Wi-Fi Antenna(s)
1 x Extension Cable for RGB strips (80 cm)
1 x ROG coaster(s)
2 x ROG weave SATA 6G cable
1 x ROG Thank you card
User¥s manual
1 x M.2 Screw Package
1 x Supporting DVD
1 x Extension cable for Addressable LED
BIOS
256 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.2, ACPI 6.2
Manageability
WOL, PXE
Operating System
WindowsÆ 10 64-bit
Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
ATX Form Factor
