Boost Clock: Up to 2825 MHzGame Clock: Up to 2685 MHz
Stream Processors
1024
Infinity Cache
16MB
Ray Accelerators
16
Memory Size/Bus
4GB GDDR6
Memory Clock
18 Gbps Effective
Displays
Maximum 2 Displays
Resolution
HDMI™: 7680×4320DisplayPort1.4: 7680×4320
Interface
PCI-Express 4.0 x4
Output
1x HDMI 1x DisplayPort
BIOS Support
UEFI
Game Index
1080P
Sapphire Features
Premium Digital Power DesignFuse ProtectionDual-X Cooling TechnologyIntelligent Fan ControlPrecision Fan ControlMetal BackplateTriXX SupportedTriXX BoostAMD FeaturesAMD RDNA 2 Gaming ArchitectureDirectX 12 Ultimate supportAMD Smart Access MemoryAMD Infinity Cache6nm GPUPCI Express 4.0 supportAMD FreeSync TechnologyDisplayPort 1.4 with DSCHDMI supportVideo Streaming up to 8KAMD Radeon VR Ready PremiumAMD FidelityFXAMD Radeon Image SharpeningAMD Radeon Anti-LagAMD Radeon SoftwareGame Driver Optimizations
Cooler Type
Dual Fans
Form Factor
2 slot, ATXDimension: 194(L)X 107(W)X 40(H)mm
Power Consumption
130W (Board Power)
OS
Linux®, Windows® 7*, Windows® 10, and Windows 11 64-bit operating system required
System Requirement
Minimum 400 Watt Power Supply1 x 6-pin Power Connector.PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.Minimum 8GB of system memory. 16GB recommended.
